The tuning kit manipulates the speed signal without altering the motor's power relative to pedaling speed. This guarantees a smooth motor control without speed limit interruptions. Depending on a tuning kit, some determine when assistance stops, while others remove the restriction entirely for continuous support. However, the achievable speed mostly depends on the eBike model. Achievable speed can be calculated using a simple formula:
Speed = Cadence [rpm] * Wheel circumference [mm] * Front Chainring Teeth / Rear Chainring Teeth * 60 [min/h] / 1.000.000 [mm/km]
After installation, your tuning kit will be activated with the activation of your eBike. This tuning kit can be activated / deactivated also, but only by your choise, you do not need to do it everytime you turn On ebike.
Activation and deactivation:
- Turn the ebike off and on again. Do not move it or do other operations.
- Raise the rear wheel, give a strong pedal with the longest (hardest) gear engaged.
- Let it run for a few seconds.
- The system recognizes the acceleration and considers it as an activation or deactivation command (cyclically). Upon activation, the display shows the speed that change from real to halved in the manner described above. When deactivated, the display shows the speed change from halved to real and the bike returns to its original state.
